Aluminum Foil Coated Fiberglass Fabric/ Aluminum Foil Laminated Fiberglass Fabric
Fiberglass fabrics increase the properties for heat radiant resistance after laminated with aluminum foil.
It is used for daily precision apparatus protection, safety defender for manufacture, storage, and transportation of danger tinder, and can offer better protection for different kinds of piping system outside.
1. Structure: Aluminum foil / Metalized film+adhesive (Hydrogel /acrylate adhesive )+fiberglass
2. Certificate: With ISO9001 certificate
3. Advantage: high Adhesion Strength and low moisture vapor transmission rate
Super holding power to offer reliable and durable
Good fire-proof and insulated material to save energy
Application:
1.Used as the thermal insulating materials of steam heating pipelines, sound -proof materials in construction and protective layer of super glass wool and rock wool with excellent functions of fire -resistant, anti-corrosion, heat isolation and sound absorbability.
2.Used as packing materials for the export equipment with the functions of damp proof, mildew proof, fire -existence and anticorrosion.
3.Used for wrapping materials of oil transportation pipelines and steam pipelines in petrochemical industry with the same effects as mentioned above.
Specific Applications :
Protective layer of super glass wool and rock wool.
Insulator for tubes and ducts.
Flame retardant insulation covering.
Thermal barrier.
Thermal shield.
Covers against fires.
Radiant heat protector.
Thermal insulator.
Cases for drums or pallets.
Plumbing blowtorch welding blanket.
Protector of torch welding.
Heat engine insulator.
Specifications:
|
Item No.
|
Thickness of foil (micron)
|
Fiberglass Weight
|
Thickness(mm)
|
Width(Meter)
|
Weave
|
|
AL-95
|
7/14/18 Aluminized film F.R Alum.Foil
|
95 g /m2
|
0.1
|
1/1.2
|
Plain
|
|
AL-100
|
7/14/18 Aluminized film F.R Alum.Foil
|
100 g /m2
|
0.12
|
1/1.2
|
Plain
|
|
AL-110
|
7/14/18 Aluminized film F.R Alum.Foil
|
110 g /m2
|
0.12
|
1/1.2
|
Plain
|
|
AL-130
|
7/14/18 Aluminized film F.R Alum.Foil
|
130 g /m2
|
0.15
|
1/1.2
|
Plain
|
|
AL-140
|
7/14/18 Aluminized film F.R Alum.Foil
|
140 g /m2
|
0.15
|
1/1.2
|
Plain
|
|
Al-7628
|
7/14/18 Aluminized film F.R Alum.Foil
|
200 g /m2
|
0.2
|
1/1.2
|
Plain
|
|
AL-3732
|
7/14/18/ Aluminized film F.R Alum.Foil
|
430 g /m2
|
0.4
|
1/1.2
|
Twill
|
|
AL-84215
|
7/14/18/25 Aluminized film F.R Alum.Foil
|
300 g /m2
|
0.5
|
1/1.5
|
Plain
|
|
AL-FW600
|
7/14/18/25 Aluminized film F.R Alum.Foil
|
600g /m2
|
0.6
|
1
|
Even grain check
|
|
AL-2025
|
7/14/18/25 Aluminized film F.R Alum.Foil
|
600 g /m2
|
0.8
|
1/1.5
|
Plain
|
|
AL-3784
|
7/14/18/25 Aluminized film F.R Alum.Foil
|
880g /m2
|
0.9
|
1
|
8HS Satin
|
|
Various based fabrics are available to order |
|||||
